MX FPGAs

MX Family of Antifuse FPGAs

Featuring low power and design security, MX FPGAs offer a reliable, single-chip ASIC alternative. MX devices provide high performance while shortening the system design and development cycle. Offering an efficient, flexible 5.0V architecture, MX FPGAs are ideal high-volume platforms for integrating your legacy PLDs into a single device.

Key Benefits

Low power consumption
Ability to be live at power-up
High-performance mixed-voltage solution
PCI compliance
Embedded dual-port SRAM modules
Availability in military and automotive temperature grades

Buy Now

Products

Device	A40MX02	A40MX04	A42MX09	A42MX16	A42MX24	A42MX36
Capacity
System Gates	3,000	6,000	14,000	24,000	36,000	54,000
SRAM Bits						2,560
Logic Modules
Sequential			348	624	954	1,230
Combinatorial	295	547	336	608	912	1,184
Decode					24	24
Clock-to-Out	9.5 ns	9.5 ns	5.6 ns	6.1 ns	6.1 ns	6.3 ns
SRAM Modules (64×4 or 32×8)						10
Dedicated Flip-Flops			348	624	954	1,230
Clocks	1	1	2	2	2	6
Maximum Flip-Flops	147	273	516	928	1,410	1,822
User I/O (Maximum)	57	69	104	140	176	202
PCI					Yes	Yes
Boundary Scan Test (BST)					Yes	Yes
Speed Grades	-F, Std.,	-F, Std.,	-F, Std.,	-F, Std.,	-F, Std.,	-F, Std.,
Speed Grades	-1, -2, -3	-1, -2, -3	-1, -2, -3	-1, -2, -3	-1, -2, -3	-1, -2, -3
Temperature Grades¹	C, I, M, A	C, I, M, A	C, I, M, A	C, I, M, A	C, I, M, A	C, I, M, A, B
Packages (By Pin Count)
PLCC	44, 68	44, 68, 84	84	84	84
PQFP	100	100	100, 144, 160	100, 160, 208	160, 208	208
VQFP	80	80	100	100
TQFP			176	176	176
CQFP						208, 256
PBGA						272¹
CPGA			132

C = Commercial, I = Industrial, A = Automotive, M = Military, B = MIL-STD-883

Notes:

Package discontinued
